    Renewable Photovoltaic Monocrystalline Solar Cells Mono PV Panels 500watt 460w 540watt

    Ask Lasest Price
    Brand Name : ASGOFT
    Model Number : ASS540P
    Certification : CE/ CQC / TUV / ETL/CEC/ISO
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 100000 Watts
    Delivery Time : With 1~3 Weeks
    • Product Details
    • Company Profile

    Renewable Photovoltaic Monocrystalline Solar Cells Mono PV Panels 500watt 460w 540watt


    Renewable Solar Panel 500watt Monocrystalline Solar PV Panels 500w 460w 540watt


    Description:


    Advanced Solar Cell Tech and Panel Structure - ASGOFT solar panels adapted the newest 9 Bus-bars cell tech and Half-cell structure, allowing the full-size solar cell to be cut in half and closely arranged for space usage maximization. Increase the cell receiving surface while reducing current and resistance loss with a thinner ribbon design.
    Built to Last - This all-weather monocrystalline solar panel can handle snow, rain, and heat for decades with IP65 protection.
    Features:
    • 20%+ high solar cell efficiency
    • Aluminum alloy frame
    • High transparent low-iron, tempered glass
    • Rugged design to withstand high wind pressure, hail and snow load
    • Aesthetic outlook

    Specifications:


    Electrical Parameters at STC
    Module TypeASS540P
    Rate Maximum Power540
    Module Efficiency(%)20.9
    Open Circuite Volatage(Voc/v)49.55
    Short Circuit Current (Isc/A)13.89
    Voltage at Pmax (Vmp/V)41.62
    Current at Pmax (Imp/A)12.98
    Power Tolerance0~+5w
    Temperature Coefficent of Isc+0.046% °C
    Temperature Coefficent of Voc-0.276% °C
    Temperature Coefficent of Pmax-0.356% °C
    STCIrradiance 1000W/㎡ Cell Temperature 25°C AM 1.5
    Remark : Electrical data in this catalogue does not refer to a single module ,and it is not part of the offer .
    Solar Cell(Type/Size)MONO(182mm)
    Solar Cells Number144pcs (6*24)
    Dimensions2279*1134*35mm
    Weight28.5kg/pcs
    Structure3.2Glass+EVA film+Back
    FramAnodized Aluminum Alloy
    Junction BoxIP68☒3*Bypass Diode
    Cable Cross Section Size4.0m㎡,(+)300mm/(-)400mm
    Mechanical LoadFront 5400Pa/Black 2400Pa
    Packing Number31pcs/pallet
    Packing Volume3.372cbm/pallet
    40'HQ Container620pcs

    Product Details :



    FAQ
    1. Who are we? What we do?
    We are based in Shenzhen, China, focus on ESS battery solution for clients all over the world.
    There are high-profile R&D , top management and sales teams.
    ODM/OEM is available.
    2. How do we guarantee the product warranty?
    There is 5 to 10 years' warranty period.
    3.How long is the lead time of sample order and production order?
    About 1-2 weeks for sample order.
    About 2-4 weeks for production order.
    4. How long is the shipment?
    About 2 weeks via air,3-7 weeks via sea, depending on the destination.
    5. How do we offer the after-sales service?
    We're ready for 24/7 service.
